C2505 SERIES 2.50mm pitch wire to wire connector

AC 02 85 0 05 H IF 2.50mm pitch Housing

Reference lnformations:
*Material: Nylon 66,UL94V-0
*Suitable H.R C2505F series Terminal
*Mates with H.R C2505HM series Housing

A Ordering Information & Dimensions:
B
C PART NO. Dimensions
F
ST C2505HF-02P AB
HRJ C2505HF-03P
DC C2505HF-04P 2.50 5.50
C2505HF-05P
AC 02 85 0 05 H IM 2.50mm pitch Housing C2505HF-06P 5.00 8.00
C2505HF-07P
Reference lnformations: C2505HF-08P 7.50 10.50
*Material: Nylon 66,UL94V-0 C2505HF-09P
*Suitable H.R C2505M series Terminal C2505HF-10P 10.00 13.00
*Mates with H.R C2505HF series Housing C2505HF-11P
C2505HF-12P 12.50 15.50

15.00 18.00

17.50 20.50

20.00 23.00

22.50 25.50

25.00 28.00

27.50 30.50

Unit:mm

Ordering Information & Dimensions:

PART NO. Dimensions

C2505HM-02P AB
C2505HM-03P
C2505HM-04P 2.50 8.00
C2505HM-05P
C2505HM-06P 5.00 10.50
C2505HM-07P
C2505HM-08P 7.50 13.00
C2505HM-09P
C2505HM-10P 10.00 15.50
C2505HM-11P
C2505HM-12P 12.50 18.00

15.00 20.50

17.50 23.00

20.00 25.50

22.50 28.00

25.00 30.50

27.50 33.00

Unit:mm
