C3030 SERIES 3.00mm pitch wire to wire and wire to board connector

C3030WV-F 3.00mm pitch 180° Single Row Wafer

Reference lnformations:

*Material: Pin: Brass/Tin-plated
Wafer: PBT15%GF,UL94V-0

*Mates with H.R C3030HF series single row Housing
*LCP is available

A Ordering Information & Dimensions:
B
C PART NO. Dimensions
F
ST C3030WV-F-02P AB
HRJ C3030WV-F-03P
DC C3030WV-F-04P 3.00 9.65
C3030WV-F-05P
C3030WV-F-06P 6.00 12.65
C3030WV-F-07P
C3030WV-F-08P 9.00 15.65
C3030WV-F-09P
C3030WV-F-10P 12.00 18.65
C3030WV-F-11P
C3030WV-F-12P 15.00 21.65

18.00 24.65

21.00 27.65

24.00 30.65

27.00 33.65

30.00 36.65

33.00 39.65

Unit:mm

C3030WR-F 3.00mm pitch 90° Single Row Wafer

Reference lnformations:

*Material: Pin: Brass/Tin-plated
Wafer: PBT15%GF,UL94V-0

*Mates with H.R C3030HF series single row Housing
*LCP is available

Ordering Information & Dimensions:

PART NO. Dimensions

C3030WR-F-02P AB
C3030WR-F-03P
C3030WR-F-04P 3.00 9.65
C3030WR-F-05P
C3030WR-F-06P 6.00 12.65
C3030WR-F-07P
C3030WR-F-08P 9.00 15.65
C3030WR-F-09P
C3030WR-F-10P 12.00 18.65
C3030WR-F-11P
C3030WR-F-12P 15.00 21.65
