A2001 SERIES 2.00mm pitch wire to board connector

A2001WV 2.00mm pitch 180° Wafer

Reference lnformations: Ordering Information: Ordering Information & Dimensions:
*Material: Pin: Brass/Tin-plated A2001WV-XP ＊
PART NO. Dimensions
Wafer: Nylon 66,UL94V-0 12
*Mates with H.R A2001 series Housing A2001WV-02P AB
*Nylon 6T or Nylon 46 is available 1.Part No. A2001WV-03P
2.Style: A2001WV-04P 2.00 6.00
A A2001WV-05P 4.00 8.00
B 1-Type 1 A2001WV-06P 6.00 10.00
C 2-Type 2 A2001WV-07P 8.00 12.00
F 3-Type 3 A2001WV-08P 10.00 14.00
ST A2001WV-09P 12.00 16.00
HRJ A2001WV-10P 14.00 18.00
DC A2001WV-11P 16.00 20.00
A2001WV-12P 18.00 22.00
A2001WV-13P 20.00 24.00
A2001WV-14P 22.00 26.00
A2001WV-15P 24.00 28.00
A2001WV-16P 26.00 30.00
A2001WV-17P 28.00 32.00
A2001WV-18P 30.00 34.00
32.00 36.00
34.00 38.00

Unit:mm

A2001WR 2.00mm pitch 90˚ Wafer

Reference lnformations:

*Material: Pin: Brass/Tin-plated
Wafer: Nylon 66,UL94V-0

*Mates with H.R A2001 series Housing
*Nylon 6T or Nylon 46 is available

Ordering Information: Ordering Information & Dimensions:
A2001WR-XP ＊
PART NO. Dimensions
12
A2001WR-02P AB
1.Part No. A2001WR-03P
2.Style: A2001WR-04P 2.00 6.00
A2001WR-05P 4.00 8.00
1-Type 1 A2001WR-06P 6.00 10.00
2-Type 2 A2001WR-07P 8.00 12.00
A2001WR-08P 10.00 14.00
A2001WR-09P 12.00 16.00
A2001WR-10P 14.00 18.00
A2001WR-11P 16.00 20.00
A2001WR-12P 18.00 22.00
A2001WR-13P 20.00 24.00
A2001WR-14P 22.00 26.00
A2001WR-15P 24.00 28.00
A2001WR-16P 26.00 30.00
A2001WR-17P 28.00 32.00
A2001WR-18P 30.00 34.00
32.00 36.00
34.00 38.00

Unit:mm
