F1004 SERIES 1.00mm pitch FFC/FPC connector

F1004WV 1.00mm pitch FFC/FPC 180° Connector, NON-ZIF

Reference lnformations:

*Material: Pin: Phosphor Bronze/Tin-plated
Wafer: Nylon 9T,UL94V-0

Ordering Information & Dimensions: A
B
PART NO. Dimensions PART NO. Dimensions C
F1004WV-04P AB F1004WV-20P AB F
ST
3.00 6.50 19.00 22.50 HRJ
20.00 23.50 DC
F1004WV-05P 4.00 7.50 F1004WV-21P 21.00 24.50
F1004WV-06P 5.00 8.50 F1004WV-22P 22.00 25.50
23.00 26.50
F1004WV-07P 6.00 9.50 F1004WV-23P 24.00 27.50
F1004WV-08P 7.00 10.50 F1004WV-24P 25.00 28.50
26.00 29.50
F1004WV-09P 8.00 11.50 F1004WV-25P 27.00 30.50
F1004WV-10P 9.00 12.50 F1004WV-26P 28.00 31.50
29.00 32.50
F1004WV-11P 10.00 13.50 F1004WV-27P 30.00 33.50
F1004WV-12P 11.00 14.50 F1004WV-28P 31.00 34.50
32.00 35.50
F1004WV-13P 12.00 15.50 F1004WV-29P 33.00 36.50
F1004WV-14P 13.00 16.50 F1004WV-30P
Unit:mm
F1004WV-15P 14.00 17.50 F1004WV-31P
F1004WV-16P 15.00 18.50 F1004WV-32P

F1004WV-17P 16.00 19.50 F1004WV-33P
F1004WV-18P 17.00 20.50 F1004WV-34P

F1004WV-19P 18.00 21.50

F1004WR 1.00mm pitch FFC/FPC 90° Connector, NON-ZIF

Reference lnformations:

*Material: Pin: Phosphor Bronze/Tin-plated
Wafer: Nylon 9T,UL94V-0

Ordering Information & Dimensions:

PART NO. Dimensions PART NO. Dimensions
AB AB
F1004WR-04P F1004WR-20P
F1004WR-05P 3.00 6.50 F1004WR-21P 19.00 22.50
4.00 7.50 20.00 23.50
21.00 24.50
F1004WR-06P 5.00 8.50 F1004WR-22P 22.00 25.50
F1004WR-07P 6.00 9.50 F1004WR-23P 23.00 26.50
24.00 27.50
F1004WR-08P 7.00 10.50 F1004WR-24P 25.00 28.50
F1004WR-09P 8.00 11.50 F1004WR-25P 26.00 29.50
27.00 30.50
F1004WR-10P 9.00 12.50 F1004WR-26P 28.00 31.50
F1004WR-11P 10.00 13.50 F1004WR-27P 29.00 32.50
30.00 33.50
F1004WR-12P 11.00 14.50 F1004WR-28P 31.00 34.50
F1004WR-13P 12.00 15.50 F1004WR-29P 32.00 35.50
33.00 36.50
F1004WR-14P 13.00 16.50 F1004WR-30P
F1004WR-15P 14.00 17.50 F1004WR-31P Unit:mm

F1004WR-16P 15.00 18.50 F1004WR-32P

F1004WR-17P 16.00 19.50 F1004WR-33P *

F1004WV-18P 17.00 20.50 F1004WR-34P

F1004WR-19P 18.00 21.50
