A1008010 SSEERRIIEESS 1.2050mm pitch wire to board connector

A Specifications
B
C Current rating: 1A AC,DC
F Voltage rating: 50V AC,DC
ST Temperature range: -25°C ~ +85°C
HRJ Contact resistance: 20mΩ Max.
DC Insulation resistance: 100MΩ Min.
Withstanding voltage: 500V AC/minute
Assembly layout *Contact H.R for details*

Standards

E179987

Ordering code

A1001 - T P E -C A1001 WR A - SF - 2X 20P D01

Series No. Series No.
Plating code: T=Tin-plated, G=Gold-plated Connector type: WV=Vertical, WR=Right angle
Material: P=Phosphor bronze Blank=Normal type, A=Shell type
E=Stamping before plating Mounting type: SF=SMT with boss
Option code: -C=C Type
S=SMT without boss
A1001 H - 2X 10P -1 Blank=Single row, 2X=Dual row
No. of circuits
Series No. Option code: D01=Gold-flash, Taping reel
H=Housing
Blank=Single row, 2X=Dual row
No. of circuits
Option code: -1=Type 1, -2=Type 2
