F2544 SERIES 2.54mm pitch FFC/FPC connector

AF 20 58 40 40 H I 2.54mm pitch FFC Connector Without Lock - B TYPE

Reference lnformations: Ordering Information & Dimensions:
*Material: Nylon 66,UL94V-0
*Suitable H.R F2544 series Terminal - B TYPE PART NO. Dimensions
*Mates with H.R A2541 series Wafer
F2544H-02P-B AB
A F2544H-03P-B
B F2544H-04P-B 2.54 5.08
C F2544H-05P-B 5.08 7.62
F F2544H-06P-B 7.62 10.16
ST F2544H-07P-B 10.16 12.70
HRJ F2544H-08P-B 12.70 15.24
DC F2544H-09P-B 15.24 17.78
F2544H-10P-B 17.78 20.32
F2544H-11P-B
F2544H-12P-B 20.32 22.86
F2544H-13P-B
F2544H-14P-B 22.86 25.40
F2544H-15P-B
F2544H-16P-B 25.40 27.94
F2544H-17P-B 27.94 30.48
F2544H-18P-B 30.48 33.02
F2544H-19P-B 33.02 35.56
F2544H-20P-B 35.56 38.10
F2544H-21P-B 38.10 40.64
F2544H-22P-B 40.64 43.18
F2544H-23P-B 43.18 45.72
F2544H-24P-B 45.72 48.26
F2544H-25P-B 48.26 50.80
50.80 53.34
53.34 55.88
55.88 58.42
58.42 60.96
60.96 63.50

Unit:mm

FA 20 58 40 40 H I 2.54mm pitch FFC Connector With Lock - A TYPE

Reference lnformations:

*Material: PBT30%GF,UL94V-0
*Suitable H.R F2544 series Terminal - A TYPE
*Mates with H.R A2541 series Wafer

Ordering Information & Dimensions:

PART NO. Dimensions
AB

F2544H-02P-LA 2.54 5.08

F2544H-03P-LA 5.08 7.62

F2544H-04P-LA 7.62 10.16

F2544H-05P-LA 10.16 12.70

F2544H-06P-LA 12.70 15.24

F2544H-07P-LA 15.24 17.78

F2544H-08P-LA 17.78 20.32

F2544H-09P-LA 20.32 22.86

F2544H-10P-LA 22.86 25.40

* F2544H-11P-LA 25.40 27.94
F2544H-12P-LA 27.94 30.48
F2544H-14P-LA 33.02 35.56

Unit:mm
