A1273 SERIES 1.27mm pitch wire to board connector

A1273WR 1.27mm pitch 90° Single Row Pin Header

Reference lnformations:

*Material: Pin: Brass/Gold-flash
Wafer: Nylon 6T,UL94V-0

*Optional Dim. available but MOQ requested

Ordering Information & Dimensions: A
B
PART NO. Dimensions PART NO. Dimensions C
AB AB F
A1273WR-03P A1273WR-18P ST
A1273WR-04P 2.54 3.81 A1273WR-19P 21.59 22.86 HRJ
A1273WR-05P 3.81 5.08 A1273WR-20P 22.86 24.13 DC
A1273WR-06P 5.08 6.35 A1273WR-21P 24.13 25.40
A1273WR-07P 6.35 7.62 A1273WR-22P 25.40 26.67
A1273WR-08P 7.62 8.89 A1273WR-23P 26.67 27.94
A1273WR-09P 8.89 10.16 A1273WR-24P 27.94 29.21
A1273WR-10P 10.16 11.43 A1273WR-25P 29.21 30.48
A 1 2 7 3 W R - 11 P 11.43 12.70 A1273WR-26P 30.48 31.75
A1273WR-12P 12.70 13.97 A1273WR-27P 31.75 33.02
A1273WR-13P 13.97 15.24 A1273WR-28P 33.02 34.29
15.24 16.51 34.29 35.56
35.56 36.83
A1273WR-14P 16.51 17.78 A1273WR-29P 36.83 38.10
38.10 39.37
A1273WR-15P 17.78 19.05 A1273WR-30P 39.37 40.64
A1273WR-16P 19.05 20.32 A1273WR-31P
A1273WR-17P 20.32 21.59 A1273WR-32P Unit:mm

*
